Overview of System Testing and End-to-end testing:
End-to-end testing and system testing always go hand in hand, but even an experienced test professional can get confused about the vast benefits that each offer and choose only one.
In this article, we will try to debate between End-to-end testing and System testing. In order to understand the difference between that, we will first understand what are the different stages that any developing product goes through.
Table of Contents:
- System Testing Vs End-To-End testing
- Life of a Software Product under Test
- What is System Testing?
- Why is System Testing Important?
- When to Kick off System Testing?
- What is End-to-End Testing?
- Why is End to End Testing Important?
- When to Kick Off End to End Testing?
- Difference between System Testing and End-to-End Testing
- System Testing or End-to-End Testing or Both?
- Conclusion
- Was this helpful?
- Recommended Reading
System Testing Vs End-To-End testing
In the Software industry, we are always in a dilemma of choosing between a faster release and a quality release but there is always a fine balance between them. We all expect speed as well as quality at the same time, which is quite a tougher one.
Life of a Software Product under Test
The lifecycle of a product starts once the business requirements are obtained from the client. The concerned team which is responsible for it will do a thorough analysis of the same and further design the technical specifications.
These specifications will help the technicians or developers to kick-start their job in software development. The steps involved here are explained below for your easy understanding.
Step #1: Based on a high-level product description, a software product is categorized into different modules and then into components or units. These units are developed independently so that their development can continue in parallel by engaging multiple developers.
Once developed, these units will be tested individually which will fall under Unit Testing.
Step #2: Individual validation ensures that all the units of a system are performing as expected on functional as well as feasibility grounds. These components, modules, and subsystems are integrated with the next level and then tested as an integrated unit in Integration testing.
Step #3: System Testing comes into the picture in this step where the integrated product will be tested for the first time as a whole in a pseudo-production environment. This level of testing is performed to check the compliance against functional as well as non-functional business requirements.
Step #4: It is a level of testing that is performed for client acceptability and hence, called Acceptance Testing. This will be performed just before handling the software to the client, which is the Production environment.
What is System Testing?
System testing is something which is done post Integration Testing and before Acceptance Testing of any hardware or software available.
System testing is performed to analyze the coordination of the adjoining components as one system so as to ensure if it is meeting the Quality Standards or not. The primary focus is to detect the defects within inter-assemblages by performing functional & non-functional tests on the integrated product.
Non-functional tests are performed to ensure if the developing product will stand up to the business expectations or not. They are carried out to determine the response time of an application or to check on the compatibility or handling installation, performance, regression, scalability, security, and a few other areas.
Hence, an application needs to clear both functional & non-functional levels to ensure if it is up to market standards else, it can spoil the company’s reputation.
Let me explain with the help of an example of a cab booking mobile application like Uber:
Uber provides a facility for booking cabs online and it has various modules like location tracking, payment gateways, cab fares, and driver profiles which can be tested independently as part of Unit testing.
Once these modules work independently, they are integrated to test and ensure that they are working with each other under Integration testing.
Further, the customer requirements will start being validated only during system testing like if the customer is able to find a cab nearest to his location or if they are able to make payment to Uber using their choice of payment methods, etc.
Validating these scenarios is covered in System testing.
Why is System Testing Important?
System testing is required as developers/testers need to check on a few aspects before moving to the next level.
A few aspects include:
- Needs to be sure of the operation of the software as a unit.
- Needs to check if a product doesn’t skip any functional & non-functional requirements.
- Needs to test the product in a production-like environment.
- Needs to check the product with production-like data.
System Testing includes scenarios based on business risks, use cases, or high-level descriptions of product behavior. Cases related to interactions with different system resources should also be a part of system testing.
Hence, it should be conducted by someone who has complete knowledge of the required product both at the architecture level as well as the business level. Internal knowledge at the coding level is not required but system knowledge is mandatory for the tester.
Generally, a separate team would be assigned with the task of System Testing, and the team would design their own system test plans & system test cases, which would be different from the ones performed earlier in terms of test coverage. If required, multiple iterations of system testing can be performed in several environments.
When to Kick off System Testing?
System testing can be kicked off when:
- Unit testing has been closed successfully for all the units without any open defects.
- All unit-tested components are integrated well & Integration testing has been performed successfully.
- A pseudo-production environment is available to test the system product.
- The system Tester is aware of all the in/outs of the system and is ready with the test artifacts.
What is End-to-End Testing?
Testing software is an important parameter of Software Quality Assurance. A good quality product always gives a higher level of satisfaction to both the inventors as well as the buyer. To put it, in other words, a qualified or a premium product is a result of thorough regression and removal of the defect at every level.
As explained by the name itself, end-to-end testing is one of the testing levels where an application flow is tested in conjunction with the dependent systems. This is done to ensure smooth interaction with the backend & frontend applications such as databases or GUI using network channels and hence is referred to as Chain Testing as well.
Unlike system testing, user interface testing does not play any significant role here but the check is on the underlying data that puts the interface in functioning mode. End-to-end testing is usually performed once the product qualifies for System Testing.
Continuing our Example of Uber in the end-to-end testing phase, we will validate the complete customer journey
Opening the app on user mobile ->finding a cab for entered destination ->Tracking the cab before or during the ride-> completing the ride and paying using one of the payment options -> finally credit settling into the driver’s account.
Running through this end-to-end flow ensures that the customer is able to fulfill their needs. This testing is important to identify customer experience issues, especially related to multiple systems coming together.
Why is End to End Testing Important?
End-to-End testing plays an important role when the developed product needs to be a distributed system and is required to function collectively with the other systems in various environments. In such scenarios, a 360-degree check is required to ensure accurate interaction across different platforms & environments.
The main objectives of end-to-end testing include:
- Make sure that the developed product is well coordinated with any of its sub-systems, which may or may not be owned by us.
- Check on all of the system flows from the source system to the destination system.
- To validate the requirements from an end-user perspective.
- Identify issues in environments that are heterogeneous.
If required, repeatable tests should be conducted to keep a check on the health of the application. At times situations may arise where we see a conflict between the developer and tester on the grounds of understanding the impacted application areas due to minor code changes.
Developers might think of the change as minimal but that evolution is significant enough to re-execute the end-to-end test scenarios for a complete system. However, this could possibly push the delivery dates & may increase the costs as well.
When to Kick Off End to End Testing?
End to End testing is usually performed-
- Once a product qualifies for System Testing wherein all the functional aspects are covered.
- When dependent environments are identified and available to conduct flow level execution.
- When a tester is equipped with the required knowledge and test artifacts.
- When the tester has the appropriate tools that can analyze the data flow.
Difference between System Testing and End-to-End Testing
Given below are a few differences between System Testing and End-to-End Testing:
System Testing | End to End Testing |
---|---|
Developed product is tested against the product specific technical requirements identified based on business requirements. | Developed product is tested along with dependent systems as per business requirements. |
Covers functional as well as non-functional aspects of testing. | Covers interface-levels of testing considering all source and destination systems. |
Carried out towards end of software development life cycle. | Performed once product qualifies integration testing. |
All implemented features for the product would be scrutinized to uncover unexpected results. | Process flows will be checked along with front end & backend & middle-tier systems. |
Tester should have strong understanding of functionality of developed product. | Tester should have strong understanding of data flows and work flows within the system. |
System tester need not care about the stages of product development life cycle. | End-to-end tester needs to understand all stages. |
System Testing or End-to-End Testing or Both?
Often, System Testing & End-to-End Testing is considered to be the same but that is not true. Both are different forms of testing with different test coverage.
While end-to-end testing checks on the flow of activities from scratch to the end of the system covering all dependent systems, System Testing will check the same functionality with a different set of inputs to evaluate the response.
Hence, the test coverage for both types of testing will be different.
Conclusion
A system tester needs to have the mindset of real users whereas an end-to-end tester needs to understand the upstream and downstream systems equally.
As explained above, both types of testing hold equal importance in the product development cycle and hence, are required to unearth the defects of different categories.
Hope you had a clear idea of which testing to opt out of? Meanwhile, feel free to share your experiences in the comments section below.
